As AI, cloud computing, and big data workloads accelerate, the demand for ultra-high bandwidth in data centers is rapidly rising. Designed to meet the growing needs of large-scale computing and high-performance networking, the 800G QSFP-DD DR8 optical module has emerged as a critical solution for next-gen data center infrastructure.

1. What Is 800G QSFP-DD DR8?

The 800G QSFP-DD DR8 is a high-speed optical transceiver based on the QSFP-DD (Quad Small Form-factor Pluggable Double Density) interface standard. Utilizing 8 lanes of 100Gbps PAM4 signaling, it delivers a total throughput of 800Gbps per module.

Compliant with IEEE 802.3cu, the DR8 format supports up to 500 meters transmission over single-mode fiber (SMF) using 8 parallel channels, making it ideal for short-reach, high-bandwidth connections such as within data center fabrics.

a. Key Features and Practical Benefits

✅ Ultra-High Bandwidth Density

Each module supports 800Gbps transmission via 8x100G lanes
Perfect for AI/ML training clusters requiring large-scale parallel data movement

✅ Low Power Consumption

Compared to using multiple 100G or 400G modules, DR8 reduces system power draw
Helps achieve energy-efficient, greener data center operations

✅ Hot-Pluggable and Easy to Deploy

Based on the QSFP-DD form factor, it’s compatible with many existing switch platforms
Enables easy network upgrades and scalability

✅ Optimized for Scalable Architectures

Ideal for Spine-Leaf architectures, AI fabrics, and distributed compute environments
Delivers high-bandwidth, low-latency links across core network layers

b. Key Use Cases for 800G QSFP-DD DR8

✅ AI Training Clusters

Modern AI models (GPTs, large LLMs) demand massive data bandwidth for multi-GPU parallel training. DR8 modules offer the high-throughput interconnect needed to support next-gen model training at scale.

✅ Core-to-Core Data Center Interconnects

Used to connect spine and leaf switches in high-density data centers, DR8 provides low-latency, high-bandwidth links between switches and routing layers.

✅ High-Density Switch Deployments

With a compact QSFP-DD form factor, DR8 allows more ports per RU, maximizing rack space and enabling modular scale-out infrastructure.

✅ Hyperscale & Cloud Environments

Cloud service providers like AWS, Google Cloud, Microsoft Azure, and others are adopting 800G to meet the demands of massive multi-tenant networks and real-time services.

2. Compatibility & Network Flexibility

800G DR8 modules are supported by leading switch vendors including Cisco, Juniper, Arista, and NVIDIA. They are interoperable across compliant QSFP-DD platforms and can even be used in breakout scenarios for 2x400G or 8x100G connectivity when needed.

This makes DR8 a highly flexible solution for modern, evolving network topologies.

3. Why DR8 vs. FR4 or 2xFR4?

Module Type	Channels	Reach	Best Use Case
DR8	8×100G	500m	Spine-to-Leaf, AI interconnects
FR4	4×100G	2km	Campus/metro or cross-datacenter
2xFR4	2×400G	2km	Dual-port usage (Leaf → Server)

Conclusion: For short-distance, high-bandwidth intra-data center links, DR8 offers the best balance of performance, density, and cost-efficiency.

Conclusion: The Practical Future of Data Center Networking

The 800G QSFP-DD DR8 module is a cornerstone for building high-performance, scalable, and future-ready data center networks. With its massive throughput, low power draw, and interoperability, it’s poised to support the next wave of AI computing, cloud workloads, and hyperscale architectures.

Whether you’re upgrading existing infrastructure or building out a next-gen AI cluster, QSFP-DD DR8 is a future-proof choice for high-speed, high-efficiency connectivity.

About Optech Technology Co. Ltd

Optech Technology Co. Ltd was founded in 2001 in Taipei, Taiwan. The company was created with a sole purpose, to provide a wide and high quality portfolio of optical products to a very demanding and fast evolving market.

To respond to the permanent increase of IP traffic, Optech portfolio is constantly growing. Since the beginning, the company has always been up to date with the latest innovations on the market. Today, we are proud to deliver a large selection of 25G SFP28, 40G QSFP+, 100G QSFP28, 200G QSFP56, 400G QSFP-DD, 800G QSFP-DD and OSFP optical transceivers and cables.

Optech has a large portfolio of products which include optical transceivers, direct attach cables, active optical cables, loopback transceivers, media converters and fiber patch cords.

Through its large selection of optical products, that have a range of data speed from 155 Mbps to 800 Gbps and reach distances up to 120km, Optech products are suitable for various industries such as telecom, data centers as well as public and private networks.

Part Number	Optech Part Number	Features	*Note*
800G QSFP-DD DR8	OPDM-SX5-13-CB	800Gb/s QSFP-DD DR8 single mode mode, MPO, 1310nm, up to 500m	800G QSFP-DD DR8+ is also available

For additional information about the 800G QSFP-DD DR8, or price inquiry, please contact us at sales@optech.com.tw
