Optech Technology is proud to announce that the 400G QSFP112 SR4 is compatible with Nvidia MMA1Z00-NS400 !
For more information or to order the 400G QSFP112 SR4, contact us at sales@optech.com.tw.
Features of the 400G QSFP112 SR4 Optical Transceiver
The 400G QSFP112 SR4 transceiver supports connections over multi mode fiber (MMF) up to 50m. It uses single MPO-12/APC optical connector. The wavelengths is 850nm.
- Supports 425Gb/s aggregate bit rate
- 4 Parallel optical lanes
- MPO-12 connector
- Operating case temperature: 0°C ~70C
- Maximum power consumption 8W
- Optical Interface: IEEE 802.3db compliant
- Electrical Interface IEEE 802.3ck 400GAUI-4
- Up to 50m transmission over OM4 with KP4 FEC
- QSFP112 MSA compliant
- RoHS compliant
- CMS compliance
Application of the 400G QSFP112 SR4 Transceiver
- Application case1: 1x400G SR4, 1 of 400G per port point to point connections
- Application case2: 4x100G SR, 4 of 100G per port point to point connections
Nvidia MMA1Z00-NS400 Compatible
Optech’s 400G QSFP112 SR4 transceiver is fully compatible with Nvidia devices. The Nvidia MMA1Z00-NS400 compatible was tested on Nvidia QM9790 switch.
To ensure the compliance and the performance of our transceivers, all our products are carefully verified in our testing lab.
To see the complete Nvidia compatible list, click here.
Ordering Information.
| Optech Part Number | Nvidia Part Number | Features |
| OPEY-MT5-85-CB4 | MMA1Z00-NS400 | 400Gb/s QSFP112 SR4 multimode, MPO, 850nm, up to 50m |
For additional information about the Nvidia MMA1Z00-NS400 Compatible 400G QSFP112 SR4 transceiver, or price inquiry, please contact us at sales@optech.com.tw
About Optech
Optech Technology Co. Ltd was founded in 2001 in Taipei, Taiwan. The company was created with a sole purpose, to provide a wide and high quality portfolio of optical products to a very demanding and fast evolving market.
To respond to the permanent increase of IP traffic, Optech portfolio is constantly growing. Since the beginning, the company has always been up to date with the latest innovations on the market. Today, we are proud to deliver a large selection of 25G SFP28, 40G QSFP+, 100G QSFP28, 200G QSFP56, 400G QSFP-DD, 800G QSFP-DD and OSFP optical transceivers and cables.
Optech has a large portfolio of products which include optical transceivers, direct attach cables, active optical cables, loopback transceivers, media converters and fiber patch cords.
Through its large selection of optical products, that have a range of data speed from 155 Mbps to 800 Gbps and reach distances up to 120km, Optech products are suitable for various industries such as telecom, data centers as well as public and private networks.
